LED Well Glass

1100.00

Our LED Street Light – Lens Model is meticulously designed to deliver superior light control, energy efficiency, and long-term durability. Utilizing high-performance LED chips in combination with engineered optical lenses, this model offers precise light distribution tailored to the specific requirements of roadway and area lighting applications. The lens model is ideal for projects requiring uniformity, low glare, and compliance with photometric standards. Built with corrosion-resistant die-cast aluminum housing and toughened glass lens for extreme durability.

Watt

Color

Get a quote

Specifications

Environmental
Working Temperature	-10 °C to + 45 °C
Working Humidity	10 to 90% RH
Storage Temperature	0°C TO + 85 °C
IP Rating	IP65
IK Rating	IK07
Standards Compliance
Standards	Voltage Fluctuations, Flicker (EN 61000-3-3) Harmonics Current (EN 61000-3-2) Surge Immunity (EN 61000-4-5) EMC: 4kV/CM:6kV (EN 61547)
Physical Details
Material	Aluminium Die casting + PC opal diffuser
Suitable Fixing	By using Bracket: Ceiling/Surface Mount,Eye bolt: Hanging by chain kit
Cable Entry	IP68 Gland -Single Entry
Housing Color	Powder Coated - Gray
Applications	Indoor Industrial environment
Application Area	Suitable for refineries,Raiway platform, Industrial Plants & Units Toll Plaza, Warehouse
Warranty	2 Years

Product Details
Model	LED Well Glass
Make	SHINE PLUS
Electrical Data
Power Consumption	20W/30W/ 35W/40W/ 50W/ 60W/70W
Operating Voltage Range	140VAC-265VAC
Frequency	50 Hz
THD	<10%
Power Factor	> 0.96
Driver	Constant Current (External)
Efficiency	> 86%
Light Data
Light source (LED)	Lumiled /Osram /Bridgelux, SDCM <3
Beam Angle	Wide >160 Degree
Efficacy	100 lm/Watt
Colour temperature	6500K
CRI	>80
Average Life	L70 B50 @50,000 Hours
