Q-Series High Bays

4400.00

The Premium LED High Bay Light is a cutting-edge lighting solution designed for high-ceiling environments that demand superior performance, energy efficiency, and long-term reliability. Engineered for warehouses, manufacturing plants, logistics centers, gymnasiums, and large retail spaces, this luminaire combines industry-leading components with intelligent design to deliver outstanding light output, durability, and smart control options. Delivers up to 160 lm/W system efficiency, dramatically reducing energy consumption. Diamond design Die-cast aluminum body with integrated high-density heat sink fins for maximum heat dissipation

Watt

Color

Get a quote

Specifications

GENERAL INFORMATION
Driver included	Yes
CE mark	Yes
RoHS compliant	Open circuit protection, Short circuit protection, Overvoltage protection
Testing standard	LM-79 -19
HOUSING AND FINISH
Housing	Aluminium
Optic	Polycarbonate
Protector	Polycarbonate (with integrated lenses)
UGR	> 20
Housing finish	Electrostatic polyester powder coating
Standard colour(s)	RAL 9017 black
Tightness level	IP 65
Impact resistance	IK 09
OPERATING CONDITIONS
Operating temperature range (Ta)	-20°C to + 45°C
Operating Humidity	10-90%RH
Mounting Option	Loop Hanging ,Bracket Mounting
LIFETIME OF THE LEDS @ TA 25°C
L80B10	>50,000 Hrs
Switching cycles	>100,000 times

PERFORMANCE
Power	100W/150W/200W
Efficacy	160lm/W
Power Efficiency	≥93%
Start Time	≤0.2S
Warm-up time to 60%	0.5s
ELECTRICAL INFORMATION
Nominal voltage	120-277V ︱ 50/60Hz
Power factor (at full load)	0.9
Surge protection options (kV)	6KV-Line-Line , 6KV-Line-Earth
Electromagnetic compatibility (EMC)	EN 61000 3-2:2019, EN 61000-3-3:2013
Sensor	Motion sensor (optional)
Total Harmonic	IEC 61000-3-2
Distortion(THD)	> < 12%
Driver Type	IEC 61000-3-2
Overvoltage protective devices which comply with IEC 61643-11 shall be disconnected from the circuit.
withstand voltage	1.5KV 60S 10mA
OPTICAL INFORMATION
LED Type	SMD2835
Beam Angle	60° / 90° / 120°
Recommended installation height	135 lm/Watt
Color Tolerance	6500K
LED colour temperature	>80
Colour rendering index (CRI)	L70 B50 @50,000 Hours
Upward Light Output Ratio (ULOR)	0%
